Input/output (I/O) modules
5-77
Analogue output modules
5.10.1 PCD2.W4x0, analogue outputs, 4 channels, 8 bit resolution
Application
High-speed output module with 4 output channels of 8 bits each. Different output
signals can be chosen with the aid of jumpers. Suitable for processes in which a
large number of actuators have to be controlled, such as in the chemical industry and
building automation.
Module overview
PCD2.W400: Simple module with 4 output channels of 8 bits each. 0 … 10 V
PCD2.W410: General purpose module with 4 output channels of 8 bits each.
Signals can be selected from 0 … 10 V, 0 … 20 mA or 4 … 20 mA.
Technical data
Number of output channels: 4, short circuit protected
Signal ranges: W400 0 … 10 V
W410 0 … 10 V*) selectable
0 … 20 mA with jumpers
4 … 20 mA
*) Factory setting
Resolution (digital representation): 8 bits (0 … 255)
Conversion time D/A: < 5 µs
Load impedance: for 0 … 10 V: ≥ 3 kΩ
for 0 … 20 mA: 0 … 500 Ω
for 4 … 20 mA: 0 … 500 Ω
Accuracy (of output value): for 0 … 10 V: 1 % ± 50 mV
for 0 … 20 mA: 1 % ± 0.2 mA
for 4 … 20 mA: 1 % ± 0.2 mA
Residual ripple: for 0 … 10 V: < 15 mVpp
for 0 … 20 mA: < 50 µApp
for 4 … 20 mA: < 50 µApp
Temperature error: typically 0.2 %, (across temperature range 0 … +55 °C)
Burst protection:
(IEC 801-4)
± 1 kV, with unshielded cables
± 2 kV, with shielded cables
Internal current consumption:
(from +5 V bus)
1 mA
Internal current consumption:
(from V+ bus)
30 mA
External current consumption: max. 0.1 A (type PCD2.W410 only, for current
outputs)
Terminals: Pluggable 10-pole screw terminal block
(4 405 4847 0), for wires up to 1.5 mm²
}
