5.10 Analogue output modules
PCD2.W400 4 analogue outputs 8 bit, 0 … 10 V
PCD2.W410 4 analogue outputs 8 bit, 0 … 10 V, 0 … 20 mA, 4 … 20 mA *)
PCD2.W600 4 analogue outputs 12 bit, 0 … 10 V
PCD2.W610 4 analogue outputs 12 bit, 0 … 10 V, 0 … 20 mA, 4 … 20 mA *)
*) jumper selectable
I/O modules and I/O terminal blocks may only be plugged in and removed when the
Saia PCD
®
and the external +24 V are disconnected from the power supply.
