Saia-Burgess Controls AG

Manual Manual PCD 1 / PCD 2 Series │ Document 26 / 737 EN22 │ 2013-11-26

Input/output (I/O) modules

5-90

Analogue input and output modules

5.12 Analogue input and output modules

PCD2.W500 2 analogue inputs 12 bit + 2 analogue outputs 12 bit,

0 … 10 V, -10 V … +10 V *)

PCD2.W510 2 analogue inputs 12 bit + 2 analogue outputs 12 bit,

0 … +20 mA, -20 … +20 mA *)

*) jumper selectable

I/O modules and I/O terminal blocks may only be plugged in and removed when the

Saia PCD

and the external +24 V are disconnected from the power supply.
