Input/output (I/O) modules
5-50
Analogue input modules
5.8 Analogue input modules
PCD2.W100** 4 analogue inputs 12 Bit, 0 … 10 V, -10 V … +10 V *)
PCD2.W105** 4 analogue inputs 12 Bit, 0 … +20 mA, -20 … 0 mA,
-20 mA … +20 mA *)
PCD2.W110** 4 analogue inputs 12 bit, Pt 100
PCD2.W111** 4 analogue inputs 12 bit, Ni 100
PCD2.W112** 4 analogue inputs 12 bit, Pt 1000
PCD2.W113** 4 analogue inputs 12 bit, Ni 1000
PCD2.W114** 4 analogue inputs 12 Bit, Pt 100, 0 °C … +350 °C
PCD2.W200 8 analogue inputs 10 bit, 0 … 10 V
PCD2.W210 8 analogue inputs 10 bit, 0..20 mA
PCD2.W220 8 analogue inputs 10 bit, Pt/Ni 1000
PCD2.W220Z02 8 analogue inputs 10 bit, NTC 10
PCD2.W220Z12 8 analogue inputs 10 bit, 4 × 0 … 10 V, 4 × Pt/Ni 1000
PCD2.W300 8 analogue inputs 12 bit, 0 … 10 V
PCD2.W310 8 analogue inputs 12 bit, 0 … 20 mA
PCD2.W340 8 analogue inputs 12 bit, 0 … 10 V, 0 … 20 mA, Pt/Ni 1000 *)
PCD2.W350 8 analogue inputs 12 bit, Pt/Ni 100
PCD2.W360 8 analogue inputs 12 bit, resolution ‹ 0.1 °C, Pt 1000
*) jumper selectable
**) no longer available
I/O modules and I/O terminal blocks may only be plugged in and removed when the
Saia PCD
®
and the external +24 V are disconnected from the power supply.
