Saia-Burgess Controls AG
Manual Manual PCD 1 / PCD 2 Series │ Document 26 / 737 EN22 │ 2013-11-26
Appendix
A-10
Order codes
A
Type Description Weight
Base units for 4 PCD2 I / O modules or modems
PCD1.M110 up to 64 I / Os, 1 port, 17 KBytes RAM, 16 MHz 920 g
PCD1.M125 up to 64 I / Os, up to 4 ports, 128 KBytes RAM, 16 MHz 920 g
PCD1.M135 up to 64 I / Os, up to 4 ports, 128 KBytes RAM, 25 MHz 920 g
Base units for 8 PCD2 I / O modules or modems
PCD2.M110 up to 128 I / Os, 2 ports, 128 KBytes RAM, 16 MHz 860 g
PCD2.M120 up to 255 I / Os (with C100), up to 4 ports, 128 KBytes RAM, 16 MHz 920 g
PCD2.M150 up to 255 I / Os (with C100), up to 4 ports, 128 KBytes RAM, 25 MHz 920 g
PCD2.M170 up to 511 I / Os (with PCD3.LIO), up to 6 ports, 1 MByte RAM, 25 MHz 950 g
PCD2.M480 up to 1023 I / Os (with PCD3.LIO), up to 8 ports, 1 MByte RAM, latest
μC technology, 162 MHz (230 Mips)
950 g
Expansion housings
PCD2.C100 for 8 additional I / O modules 560 g
PCD2.C150 for 4 additional I / O modules 350 g
PCD3.RIO / LIO
PCD3.C100 for 4 PCD3 I / O modules 350 g
PCD3.C110 for 2 PCD3 I / O modules 180 g
PCD3.C200 for 4 PCD3 I / O modules, 24 VDC supply integrated 350 g
PCD4.C225 Coupling bus module with 2 module sockets for I / O modules from the
PCD4 series
200 g
PCD3.T760 for 4 PCD3 I / O modules, Probus DP, 24 VDC supply integrated 380 g
PCD3.T765
1
) as PCD3.T760 + facility to implement user-specific software modules (plug-
ins)
380 g
PCD4 I / O bus modules
PCD4.C220 with 2 additional module sockets 375 g
PCD4.C260 with 6 additional module sockets 1100 g
Extension cable for expansion housing / coupling bus module
PCD2.K100 Length 0.5 m (for mounting beneath each other with ..C1.., max. distance
150 mm)
65 g
PCD2.K110 Length 0.7 m (for mounting side-by-side with ..C1..) 70 g
PCD2.K106 Length 0.7 m ( PCD2.Mxx0
⇔
PCD3.LIO) 68 g
PCD3.K010 Connector (PCD3.LIO
⇔
PCD3.LIO) 40 g
PCD2.K120 Length 2 m (for coupling bus module) 200 g
PCD8.K111 Connecting cable to PC with 9-pole connector (PC
⇔
PGU) 200 g
Additional memory components
4 502 7013 0
2
) RAM chip with 128 KBytes / 1 Mbit 12 g
4 502 7175 0
2
) RAM chip with 512 KBytes / 4 Mbit 12 g
4 502 7126 0 EPROM chip with 128 KBytes / 1 Mbit 12 g
4 502 7223 0 EPROM chip with 512 KBytes / 4 Mbit 12 g
4 502 7141 0 Flash EPROM chip with 128 KBytes / 1 Mbit 12 g
4 502 7224 0 Flash EPROM chip with 512 KBytes / 4 Mbit 12 g
PCD7.R400 Flash card with 1 MByte for PCD2.M170 / M480, for backup 6 g
1) On request.
2) Where non-SBC RAM components are used, there is a risk of losing data.
A.5 Ordercodes
