SBC PCD1 Series User Manual

Saia-Burgess Controls AG
Manual Manual PCD 1 / PCD 2 Series │ Document 26 / 737 EN22 │ 2013-11-26
Appendix
A-11
Order codes
A
Type Description Weight
Communication modules for socket A
PCD7.F110
3
) with RS-422 / RS-485 interface (electrically connected) 8 g
PCD7.F120
3
)
5
) with RS-232 interface (suitable for modem) 8 g
PCD7.F121
3
) with RS-232 interface (suitable for modem) 8 g
PCD7.F130
3
) with interface for 20 mA current loop 8 g
PCD7.F150
3
) with RS-485 interface (electrically isolated) 8 g
PCD7.F180
3
) Belimo MP-Bus (based on RS-232) 8 g
Function modules for socket B(1)
PCD2.F520
3
) with RS-232 and RS-422 / RS-485 serial interfaces
(can also be installed on socket B2)
35 g
PCD2.F522
3
) switchable between 2 × RS-232 and 1 × RS-232 (suitable for modem) 40 g
PCD2.F530
3
) with 6-digit display and RS-232, RS-422 and RS-485 serial interfaces 45 g
Field bus connections for socket B(1) and B2
PCD7.F700
3
) Profibus FMS connection 45 g
PCD7.F750
3
) Profibus DP connection (Master) 45 g
PCD7.F770
3
) Profibus DP connection (Slave) 45 g
PCD7.F772
3
) Profibus DP connection (Slave) and electrically isolated RS-485 interface 45 g
PCD7.F800
3
) LonWorks
®
connection 45 g
PCD7.F802
3
) LonWorks
®
connection and electrically isolated RS-485 interface 45 g
PCD7.F655
3
)
4
) Network connection with Ethernet module 45 g
Modem modules for I / O module socket
PCD2.T814 33.6 kbps analogue modem (RS-232 and TTL interface) 50 g
PCD2.T851 ISDN-TA digital modem (RS-232 and TTL interface) 50 g
Accessories
Batteries
4 507 4817 0 CR 2032 lithium battery (coin cell), for PCD1.M135 and PCD2.Mxx0 10 g
From electrical
dealers
Alkaline batteries, size LR03 / AAA / AM4 / Micro for PCD2.M110 / PCD2.M120
hardware version < H
Housing covers
4 104 7338 0 Housing cover for PCD1 with space cut out for PCD7.D162 terminal
4 104 7409 0 Housing cover for PCD1 with space cut out for RJ45 connector (TCP / IP)
4 104 7410 0 Housing cover for PCD2.M150 with space cut out for RJ45 connector
(TCP / IP)
Chips for rmware update
4 502 7178 0 PCD1 (order 1 per CPU) 15 g
4 502 7126 0 PCD2.M110 / M120 (order 2 per CPU) 15 g
4 502 7341 0 PCD2.M150 (order 2 per CPU) 15 g
Pluggable screw terminal blocks
4 405 4847 0 with 10 terminals (standard) 17 g
4 405 4869 0 with 14 terminals (for ..A250) 9 g
3) Please check compatibility with the base units in sections 4.1 and 4.2.
4) For PCD2.M170 / M480 on socket B2, for PCD2.M150 on socket B with special housing cover 4 104 7410 0, or as configured system with type-no. PCD2.M150F655
5) Not recommended for new products..
