SBC PCD1 Series User Manual

Saia-Burgess Controls AG
Manual Manual PCD 1 / PCD 2 Series │ Document 26 / 737 EN22 │ 2013-11-26
CPUs and expansion housings
3-42
Expansion of user memory
3
3.14.6 PCD2.M110/M120/M150
The user memory for these CPUs can be expanded as follows:
CPU type
HW-
version
Basic
equipment
RAM:
FW-
version
Expansion option (max.) Available
memory for
extension
memory
1)
PCD2.M150
all 128 KByte RAM: 4 MBit / 512 KByte
EPROM: 4 MBit / 512 KByte
Flash-EPROM: 4 MBit / 448 KByte
128 KByte
128 KByte
128 KByte
PCD2.M110/
M120
>H 32 KByte ≥080 RAM: 4 MBit / 512 KByte
EPROM: 4 MBit / 512 KByte
Flash-EPROM: 4 MBit / 448 KByte
128 KByte
128 KByte
128 KByte
≥006 RAM: 4 MBit / 512 KByte
EPROM: 4 MBit / 512 KByte
Flash-EPROM: 4 MBit / 448 KByte
6 KByte
6 KByte
6 KByte
PCD2.M110/
M120
H 32 KByte ≥080 RAM: 4 MBit / 512 KByte
EPROM: 4 MBit / 512 KByte
Flash-EPROM: 4 MBit / 448 KByte
128 KByte
128 KByte
128 KByte
≥006 RAM: 4 MBit / 512 KByte
EPROM: 4 MBit / 512 KByte
Flash-EPROM: 4 MBit / 448 KByte
6 KByte
6 KByte
6 KByte
PCD2.M110/
M120
≥C 32 KByte ≥080 RAM: 1 MBit / 128 KByte
EPROM: 1 MBit / 128 KByte
Flash-EPROM: 1 MBit / 128 KByte
24 KByte
24 KByte
24 KByte
< 080 RAM: 1 MBit / 128 KByte
EPROM: 1 MBit / 128 KByte
Flash-EPROM: 1 MBit / 128 KByte
6 KByte
6 KByte
6 KByte
1)Thebasememoryreleasedbytheextendedmemorycanbeconguredasextensionmemoryandusedtostore
texts and DBs
