SBC PCD1 Series User Manual

Saia-Burgess Controls AG
Manual Manual PCD 1 / PCD 2 Series │ Document 26 / 737 EN22 │ 2013-11-26
5
Input/output (I/O) modules
5-54
Analogue input modules
5.8.2 PCD2.W11x, analogue inputs, 4 channels, 12 bit resolution
for resistive temperature sensors Pt/Ni 100, 1000
High-speed, convenient module for recording absolute temperatures in the range
-50 … +150 °C or +350 °C (W114) using a resistive temperature sensor. (2-wire
connection with zero adjustment) The temperature curves are linearized in the
module itself. The resolution is 12 bits.
Module overview
PCD2.W110 4 analogue inputs for temperature measurement
with Pt 100 probes (IEC 751)
PCD2.W111 4 analogue inputs for temperature measurement
with Ni 100 probes (DIN 43 760)
PCD2.W112 4 analogue inputs for temperature measurement
with Pt 1000 probes (IEC 751)
PCD2.W113 4 analogue inputs for temperature measurement
with Ni 1000 probes (DIN 43 760)
PCD2.W114 4 analogue inputs for temperature measurement
with Pt 100 probes (IEC 751)
Technical data
Number of channels 4
Galvanic separation no
Resolution (digital representation) 12 bits (0 … 4095)
Measuring principle differential
Conversion time < 30 µs
Time between 2 measurements ≥ 1 ms
Temperature error: +10 … +30 °C max. ± 0.4 °C
0 … +55 °C max. ± 1 °C
Repeating accuracy
(multiple measurements with the
same module under the same
conditions)
± 2 LSB
Probe type 2-wire
Linearization integrated
Current sources 1 per channel
Offset setting (allows zero value to
be adjusted according to length of
cable)
separate for each channel
Sensitivity 20.475 LSB/° C (4095 … 200) or
0.0488 °C/LSB (200 … 4095)
Internal current consumption:
(from +5 V bus)
45 mA
typ. 20 mA
Internal current consumption:
(from V+ bus)
30 mA (W110/W111)
20 mA (W112/W113/W114)
External current consumption: 0 mA
Terminals: Pluggable 10-pole screw terminal block
(4 405 4847 0), for wires up to 1.5 mm²
