Input/output (I/O) modules
5-1
Overview
5 Input/output (I/O) modules
5.1 General informations
5.1.1 Overview
The summary below shows the available digital and analogue I/O modules, counters
etc. for the PCD2 series:
Type Des-
igna-
tion
No.
I/Os
or
mod
Description Input/output
signal range
Page
PCD2 digital input modules
PCD2.E110 8 I 8 8 inputs 8 ms 24 VDC 5-9
PCD2.E111 8 I 8 8 inputs 0.2 ms 24 VDC 5-9
PCD2.E112 8 I 8 8 inputs 9 ms 12 VDC 5-9
PCD2.E116 8 I 8 8 inputs 0.2 ms 5 VDC 5-9
PCD2.E160 16 I 16 16 inputs 8 ms, connection via
34-pole ribbon connector
24 VDC 5-11
PCD2.E161 16 I 16 16 inputs 0.2 ms, connection via
34-pole ribbon connector
24 VDC 5-11
PCD2.E165 16 I 16 16 inputs 8 ms, spring terminal con-
nection
24 VDC 5-14
PCD2.E166 16 I 16 16 inputs 0.2 ms, spring
terminal connection
24 VDC 5-14
PCD2 digital input modules, electrically isolated
1
)
PCD2.E500 6 I 6 6 inputs 100 … 240 VAC 5-17
PCD2.E610 8 I 8 8 inputs 10 ms, electrically isolated 24 VDC 5-19
PCD2.E611 8 I 8 8 inputs 0.2 ms, electrically isolated 24 VDC 5-19
PCD2.E613 8 I 8 8 inputs 9 ms, electrically isolated 48 VDC 5-19
PCD2.E616 8 I 8 8 inputs 0.2 ms, electrically isolated 5 VDC 5-19
PCD2 digital output modules
PCD2.A300 6 O 6 6 outputs 2 A 10 … 32 VDC 5-22
PCD2.A400 8 O 8 8 outputs 0.5 A 5 … 32 VDC 5-24
PCD2.A460 8 O 8 8 outputs 0.5 A, electrically isolated 10 … 32 VDC 5-26
PCD2.A465 16 O 16 16 outputs 0.5 A, spring terminal con-
nection
10 … 32 VDC 5-29
PCD2 digital output modules, electrically isolated
PCD2.A200 4 O 4 4 make contacts 2 A 250 VAC
50 VDC
5-32
PCD2.A210 4 O 4 4 break contacts 2 A 250 VAC
50 VDC
5-34
PCD2.A220 6 O 6 6 make contacts 2 A 250 VAC
50 VDC
5-36
PCD2.A250 8 O 8 8 make contacts 2 A 48 VAC
50 VDC
5-38
PCD2.A410 8 O 8 8 outputs 0.5 A, electrically isolated
1
) 5 … 32 VDC 5-40
1) galvanic separation of outputs to Saia PCD
®
, the channels themselves are not separated against each other
