Manual Manual PCD 1 / PCD 2 Series │ Document 26 / 737 EN22 │ 2013-11-26
5
Input/output (I/O) modules
5-2
Overview
Type Des-
igna-
tion
No.
I/Os
or
mod
Description Input/output
signal range
Page
PCD2 digital, combined I/O modules
PCD2.B100 2I +
2O +
4I/O
8 2 inputs, 2 outputs, 4 selectable as
inputs or outputs
24 VDC
5 … 32 VDC
24 VDC
5-43
PCD2 multi-functional I/O modules
PCD2.G400 10 digital inputs
2 analogue inputs 10 bit
6 analogue inputs 10 bit
8 digital outputs
6 analogue outputs 8 bit
24 VDC
0 … 10 V
Pt/Ni 1000
24 VDC
0 … 10 VDC
5-47
PCD2.G410 16 digital inputs
4 analogue inputs 10 bit
4 relay outputs
4 analogue outputs 8 bit
24 VDC
I/U/T
250 VAC
U/I
5-48
PCD2 analogue input modules
PCD2.W100 4 I 4 Analogue inputs 12 bit 0 … 10 V,
-10 … +10 V
5-51
PCD2.W105 4 I 4 Analogue inputs 12 bit 0 … +20 mA
-20 … 0 mA
-20 … +20 mA
5-51
PCD2.W110 4 I 4 Analogue inputs 12 bit Pt 100 5-54
PCD2.W111 4 I 4 Analogue inputs 12 bit Ni 100 5-54
PCD2.W112 4 I 4 Analogue inputs 12 bit Pt 1000 5-54
PCD2.W113 4 I 4 Analogue inputs 12 bit Ni 1000 5-54
PCD2.W114 4 I 4 Analogue inputs 12 bit Pt 100 5-54
PCD2.W200 8 I 8 8 analogue inputs 10 bit 0 … 10 V 5-59
PCD2.W210 8 I 8 8 analogue inputs 10 bit 0 … 20 mA 5-59
PCD2.W220 8 I 8 8 analogue inputs 10 bit Pt/Ni 1000 5-59
PCD2.W220Z02 8 I 8 8 analogue inputs 10 bit NTC 10 5-59
PCD2.W220Z12 8 I 8 8 analogue inputs 10 bit 4×0 … 10 V
4×Pt/Ni 1000
5-59
PCD2.W300 8 I 8 8 analogue inputs 12 bit 0 … 10 V 5-64
PCD2.W310 8 I 8 8 analogue inputs 12 bit 0 … 20 mA 5-64
PCD2.W340 8 I 8 8 analogue inputs 12 bit,
jumper selectable
0 … 10 V,
0 … 2,5 V
0 … 20 mA,
Pt/Ni 1000
5-64
PCD2.W350 8 I 8 8 analogue inputs 12 bit Pt/Ni 100 5-64
PCD2.W360 8 I 8 8 analogue inputs 12 bit,
resolution ‹ 0.1 °C
Pt 1000 5-64
PCD2 analogue input modules, electrically isolated
1
)
PCD2.W305 7 I 7 7 analogue inputs 12 bit 0 … 10 V 5-70
PCD2.W315 7 I 7 7 analogue inputs 12 bit 0 … 20 mA 5-70
PCD2.W325 7 I 7 7 analogue inputs 12 bit -10 … +10 V 5-70
1) galvanic separation of outputs to Saia PCD
®
, the channels themselves are not separated against each other
