SBC PCD1 Series User Manual

Saia-Burgess Controls AG
Manual Manual PCD 1 / PCD 2 Series │ Document 26 / 737 EN22 │ 2013-11-26
5
Input/output (I/O) modules
5-3
Overview
Type Des-
igna-
tion
No.
I/Os
or
mod
Description Input/output
signal range
Page
PCD2 analogue output modules
PCD2.W400 4 O 4 4 analogue outputs 8 bit 0 … 10 V 5-87
PCD2.W410 4 O 4 4 analogue outputs 8 bit,
jumper selectable
0 … 10 V,
0 … 20 mA,
4 … 20 mA
5-87
PCD2.W600 4 O 4 4 analogue outputs 12 bit 0 … 10 V 5-91
PCD2.W610 4 O 4 4 analogue outputs 12 bit,
jumper selectable
0 … 10 V,
-10 V..+10 V
0 … 20 mA,
4 … 20 mA
5-91
PCD2 analogue output modules, electrically isolated
1
)
PCD2.W605 6 O 6 6 analogue outputs 10 bit 0 … 10 V 5-96
PCD2.W615 4 O 4 4 analogue outputs 10 bit 0 … 20 mA 5-96
PCD2.W615 6 O 6 6 analogue outputs 10 bit -10 … +10 V 5-96
PCD2 analogue combined input/output modules
PCD2.W500 2I +
2O
4 2 analogue inputs 12 bit
+ 2 analogue outputs 12 bit
0 … 10 V,
-10 … +10 V
5-76
PCD2.W510 2I +
2O
4 2 analogue inputs 12 bit
+ 2 analogue outputs 12 bit
0 … +20 mA
-20 … +20 mA
5-76
PCD2 analogue combined input/output modules, electrically isolated
1
)
PCD2.W525 4 E
+ 2 A
4 4 analogue inputs 14 bit
+ 2 analogue outputs 12 bit
0 … 10 V,
0(4) … 20 mA
Pt 500 / 1000,
Ni 1000
0 … 10 V,
0(4) … 20 mA
5-81
PCD2 weighing modules
PCD2.W710 1 I 1 1-channel weighing module for 4/6-
wire weighing cells
5-100
PCD2.W720 2 I 2 2-channel weighing module for 4/6-
wire weighing cells
5-100
PCD2 thermocouple modules
PCD2.W745 4 I 4 Thermocouple module for J, K …
thermocouples
2
)
6-98 5-101
1) Galvanic separation of outputs to Saia PCD
®
, channels themselves not separated
2) Non-pluggable cage clamp terminals
