SBC PCD1 Series User Manual

Saia-Burgess Controls AG
Manual Manual PCD 1 / PCD 2 Series │ Document 26 / 737 EN22 │ 2013-11-26
5
Input/output (I/O) modules
5-4
Overview
Type Des-
igna-
tion
No.
I/Os
or
mod
Description Input/output
signal range
Page
PCCD2 fast counting I/O modules
PCD2.H100 Counting module up to 20 kHz 5-103
PCD2.H110 General purpose module up to 100 kHz
5-108
PCD2 SSI encoder modules
PCD2.H150 SSI interface module 5-110
PCD2 Positioning modules for stepping motors
PCD2.H210 Motion control module for stepper motors 5-114
Positioning modules for servo-drives
PCD2.H310 Motion control module for servo-motors
1-axis encoder 24 VDC
5-119
PCD2.H311 Same as H310, but 1-axis encoder 5 VDC 5-119
PCD2.H320 Motion control module for servo-drives
2-axis with encoder 24 VDC
5-123
PCD2.H322 Same as H320, but 1-axis (slave operation) 5-123
PCD2.H325 Motion control module for servo-drives, 2-axis with
5 V and SSI absolute value encoder
5-123
PCD2.H327 Same as H325, but 1-axis (slave operation) 5-123
