SBC PCD1 Series User Manual

Saia-Burgess Controls AG
Manual Manual PCD 1 / PCD 2 Series │ Document 26 / 737 EN22 │ 2013-11-26
4
Communication interfaces
4-21
Serial interfaces on socket A
Supply option
Common supply for control and drive
–
+
+
–
11
Port #1
Si 4 AT
PCD1/PCD2
13
10
18
19
14
15
16
17
-
/D
D
+
WD
-
-
+
+
12
Actuators
230 VAC
60 W
19 VAC
MFT programming unit
When using the PCD7.F180 connection module, the supply voltage to the PC control unit
must be at least 24 VDC, ±5 % (not the default tolerance of ±20 %).
With a separate DC or AC supply to the drives, it is especially important to ensure that the
Saia PCD
®
control unit is connected to the earth (Minus pole) of the drive supply. The earth
serves as a common base for communication.
For details, see Technical Information P+P26 / 342
“MP-Bus interface for BELIMO actuating drives”
