Manual Manual PCD 1 / PCD 2 Series │ Document 26 / 737 EN22 │ 2013-11-26
5
Input/output (I/O) modules
5-12
Digital input modules
For every 2 inputs, a 3-colour LED is tted:
LED
E0 E1 E2 E3 E4 E5 E6 E7 E8 E9 E10 E11 E12 E13 E14 E15
off 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
red 1 0 1 0 1 0 1 0 1 0 1 0 1 0 1 0
green 0 1 0 1 0 1 0 1 0 1 0 1 0 1 0 1
yellow 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1
Saia Burgess Controls provides a wide range of pre-congured cables with a 34-pole
ribbon connector at one or both ends.
These connection cables can be plugged at one end into the PCD2.E160 I/O module
and at the other end into an I/O terminal adapter.
The following adapters are obtainable from Saia Burgess Controls: terminal adapters
for connecting 3-wire sensors to individual terminals for Signal, Plus and Minus;
terminal adapters for connecting 16 I/Os with and without LED and relay interface;
and terminal adapters with changeover contacts for signal conversion for digital
output modules.
Further information can be found in the Manual on “System cables and connection system”
26/792.
The following materials can be ordered from ‘3M’:
● Socket connector 34-pole Type 3414-6600
● (Metal strain relief) *) Type 3448-2034
● (Handle for socket connector 34-pole) *) Type 3490-3
Matching cables can be ordered in reels from ‘3M’:
● Ribbon cable 34-pole,
grey with pin 1 identication Type 3770/34 or 3801/34
● Round cable 34-pole,
grey with pin 1 identication Type 3759/34
*) optional
