Saia-Burgess Controls AG

Manual Manual PCD 1 / PCD 2 Series │ Document 26 / 737 EN22 │ 2013-11-26

Guidance

2-3

PlanninganapplicationwithPCD1/2/3components



 Checkthatthemax.supplycurrentfortheCPUissufcient;itgenerallyshould

be.Inextremecases,switchtoPCD3expansionunits.



Estimate consumption from the 24 Vsupply.Useestimatedvaluesfromthe

section on “Hardware”.

Theseestimatedvaluescanbefoundinsection3.8.5,“Powerconsumptionof

PCD2/PCD3input/outputmodules”.

Note that in most applications the outputs place the heaviest load on the 24 Vsup-

ply.For16outputswithaloadcurrentof0.5 Aeach,theloadingwillbe8 A with all

outputs connected.
