Manual Manual PCD 1 / PCD 2 Series │ Document 26 / 737 EN22 │ 2013-11-26
CPUs and expansion housings
3-3
Generaltechnicaldetails
3
Noise emission
PCD2.M150/M480
according to EN50081-2: Class A (for industrial areas)
Guidanceonthecorrectuseofthesecontrolsinresidential
areas can be found at www.sbc-support.com (additional
measures).
Noise immunity PCD1/
PCD2
according to EN50082-2
Mechanism and mounting
Housingmaterial Base:
Cover:
Fibre optics: PC, crystal-clear
Mounting rail Double top-hat rail as per EN50022-35 (2 x 35 mm)
Connections
Screw terminals Unlessspeciedotherwise:forwiresof1.5mm
2
(AWG16)or
2 x 0.5 mm
2
(2xAWG20)
Plug-in screw terminals Theterminalblockmayonlybepluggedonto20times.Itmust
then be replaced, to guarantee a reliable contact
Standards / approvals
EN/IEC EN/IEC61131-2“Programmablecontrollers”
Shipbuilding ABS,BV,DNV,GL,LRS,PRS.
Please verify if your chosen product is mentioned in the
list of corresponding Type-Approval-Company under
www.sbc-support.com.
cULus-listed Please verify if your chosen product is listed in the correspond-
ingCerticateunderwww.sbc-support.com. The condition for
cULusCompliancearementionedonthesheetannexedtothe
product or can be required under www.sbc-support.com.
