Manual Manual PCD 1 / PCD 2 Series │ Document 26 / 737 EN22 │ 2013-11-26

Input/output (I/O) modules

5-103

Combined analogue I/O modules with galvanic isolation

Status Output (Register n+7)

This register (Bit 0 to 15) does contain the status of the two output channels CH0 and

CH1.

The status of each output channel is displayed on 6 bits.

Status Output:

Bit Description

Bit 0..5 CH0 Status (LOW BYTE)

Bit 8..13 CH1 Status (HIGH BYTE)

Table output status:

Bit Description

CH0 CH1

5 13 Load Resistance too high.

Only for outputs in current mode. Occurs typically if the output

circuit is open

4 12 Load Resistance too low.

Only for outputs in voltage mode. Occurs typically in case of

short circuit

3 11 Over Temperature

2 10 Not Calibrated

1 9 Over Range

0 8 Under Range
