SBC PCD1 Series User Manual

Saia-Burgess Controls AG
Manual Manual PCD 1 / PCD 2 Series │ Document 26 / 737 EN22 │ 2013-11-26
5
Input/output (I/O) modules
5-117
SSI interface modules
Block diagram
CLK
/CLK
D
/D
A 12
A 13
User PROM
FPGA
(Field Programmable
Gate Array)
PCD Bus
Input filter and adaptation 24V to 5V
Output amplifier 5 .to. 32 V
DC (Uext)
Clock
/Clock
Data
/Data
Output 12
A 14
A 15
Output 13
Output 14
Output 15
For further details, please refer to manual 26/761 “PCD2.H150 - SSI interface for
absolute encoder”.
Watchdog: This module cannot be used on the base address 240 (or 496 for the
PCD2.M17x), because it would interact with the watchdog, and would cause a
malfunction.
For details, please refer to the “Watchdog” section, which describes the correct use of
the watchdog in conjunction with PCD2 components.
