200
Using the Configurator
• Alarm 5: Level 5 - 3%/ft of smoke. Time elapsed from smoke detection is
• Alarm 6: Level 6 - Heat only alarm. If the heat level on either thermistor exceeds 1
limits.
• CO Operation: CO only alarm.
19.43 Fire Phone Configuration
You can set up an audio controller, conventional phones, voice lines, remote field phones,
master telephone handsets and telephone selectors, and you can connect them together.
You need at least an Audio Network Controller Module (ANC-5000), a Telephone Network
Controller Module (TNC-5000), a Telephone Master Controller (QMT-5302N(V)), and a
Telephone/Page Selector (QAZT-5302(DS)). The Audio Controller supports conventional fire
phone circuits or voice lines. There may also be addressable fire phone modules. If you
configure addressable fire phone modules you must also ensure that there is a voice line to
support them.
19.43.1 Adding an audio controller
• See section 19.18 on page 174 for instructions on adding an audio controller.
The Audio Network Controller Module (ANC-5000) must have a Telephone Network Controller
Module (TNC-5000) installed.
You must also specify whether the four or five lines are conventional phones or voice lines to
serve addressable phone modules. After the audio controller is added you can still edit these
attributes, or change just some of the lines between voice and conventional.
Note: Your organization needs audio systems training in order to add an audio
controller to a job. To check whether you have this training, see section 2.9 on
page 24.
