System Limits
Table 2 lists the number of frames used and provided by each device.
Table 2 Frame Count
Name Description Name in the
Configurator
Frames Used Frames Available
DSPL-420 Narrow Main
Display (4 lines by
20 characters)
Main Display 2 12
DSPL-2440 Narrow Graphic
Display
Main Display 2 12
RAXN-LCD Remote Shared
Display
Annunciator
LCD Annunciator 1
39 (13 on each
header)
RAXN-LCDG Remote Shared
Graphical Display
Annunciator (24
lines)
LCD Annunciator 1
39 (13 on each
header)
RAM-1016(TZ)(DS) Remote
Annunciator with 16
bi-coloured LEDs
LED Annunciator 2 N/A
RAM-1032(TZ)(DS) Remote
Annunciator with 32
trouble LEDs
LED Annunciator 2
You can add up to 4
RAX-1048(TZ)s to
this device
IPS-2424(DS) Zone Bypass,
Adder Annunciator
(48 Display Points)
24 Sw Adder 2 N/A
RAX-1048(TZ)(DS) Adder Annunciator
with 48 bi-coloured
LEDs (DS model
has 48 bi-coloured
LEDs and 32
trouble LEDs)
48 LED Adder 3 N/A
FDX-008(KI) Smoke Control Fan
Damper Module
HOA Sw Adder 1 N/A
AGD-048 Adder Graphic
Module with 48
supervised outputs
Graphic Adder 1 N/A
MGD-32 Master Graphic
Driver Module with
32 supervised
outputs
N/A 0 N/A
QAZT-5302(DS) Addressable
Telephone Selector
Panel
Telephone/Page
Selector
2N/A
QMP-5101N(V) Network Paging
Control Unit
Master Paging 1 N/A
