Secutron MMX Series

73
Hardware Layouts
11.3 Display Modules
Each of these Display Modules occupies one display position and mount to the display cutouts
on the following chassis:
• MMX-2003-12NDS Compact main chassis
• MMX-2003-12NXTDS Mid-size main chassis
• MMX-2017-12NDS Mid-size main chassis
• MMX-2009-12NDS Large main chassis
• ECX-0012 Expander chassis for MMX-2009-12NDS
These modules can also be mounted in the standard BB-5000 cutouts (with brackets), as well
as the MMX-BB-1000 enclosures (requires RAXN-LCD as a driver).
MMX-2017-12NDS
12 Amp Mid-
size Main
Chassis
MMX-BBX-
1072A(R)DS
FNC-2000
Network
Controller
Module and 2
adder modules
over the main
board plus 14
adder boards
and 3
annunciator or
programmable
module
Slot 3 is reserved for MR-
2300-PR or UDACT-300A if
required
FNC-2000 goes in slot 2
FOM-2000-SP is mounted
over FNC-2000
MMX-2000MNS
Main
Network
Board
MMX-BBX-
FXMNS
9 adder modules
ECX-0012
Expander
Chassis for
MMX-2009-
12N
BB-5008 and
BB-5014
(occupies 2
display positions)
2 displays
12 adder
modules
12 adder modules or any 2 of
the following 3 options:
• 6 adder modules
• 1 main board and 3 adder
modules
• 1 ANC-5000 and 1 TNC-
5000
Table 3 Chassis (Continued)
Name Description Mounts in Number of
Additional
Displays or
Adder Modules
Notes
