210
Using the Configurator
19.47.3 Insert Menu
The Insert menu contains the following commands.
Some commands may be disabled (greyed) depending on what items are selected on the user
interface.
Some items may be suppressed depending on the product.
Import Job
Imports a selected job/version from an external database or
serialized job archive and converts the job to the current
version if necessary.
Export Job Ctrl+E
Exports the current job in one of two formats: A single job
database file, or a compact, serialized archive format.
Merge Jobs
Merges a selected job into the current job, retaining all
correlations.
New Version Ctrl+W
Make a copy of the current job, assigning it the next highest
version number. The user is prompted for mandatory
comments and may also override the Author field. The Job
Name cannot be changed. The new version is un-locked for
editing.
Delete Job
Version
Ctrl+D
This command permanently deletes the current Job / Job
Version from the database.
Version
History
Display the Version History (Date, Author, Comments) for
the current job.
Compare Job
Versions
Compare two versions of the same job, or two similar jobs
of different lineage.
Convert Job
Convert a job between two models. Produces a new
version of the current job.
Validate Job
This action performs all of the steps normally performed
when preparing to send a job to the panel.
Edit Job
Toggle the lock on a job that is protected against
unintentional edits or has been down loaded to a panel.
Table 30 Insert Menu
Name Description
Add Network
Nodes
Nodes Add a network node to the job.
Add Loop
Controllers
Add an Addressable or Conventional Loop Controller to the selected
network node.
Add
Annunciators
Add an LCD or LED Annunciator to the selected network node.
Table 29 Job Menu (Continued)
Name Short cut Description
