Hardware Layouts

RAX-1048TZDS

Adder Annunciator with 48 bi-

coloured LEDs and 32 trouble

LEDs

MMX-2003-12NDS

MMX-2003-12NXTDS

MMX-2017-12NDS

MMX-2009-12NDS

ECX-0012

BB-5008(R)

BB-5014

MMX-BB-1000 series

MMX-BBX-FXMNS

RAXN-LCD

Remote Shared Display

Annunciator

MMX-BB-1000 series

BB-5008(R)

BB-5014

MMX-BBX-FXMNS

MMX-LOC

ECX-0012

RAXN-LCDG

Remote Shared Graphical

Display Annunciator (24-line

display)

MMX-BB-1000 series

BB-5008(R)

BB-5014

ECX-0012

MMX-BBX-FXMNS

RAM-216

Annunciator with 16 bi-coloured

LEDs

Mounts to a 4 gang electrical

box.

RAM-208

Annunciator with 8 bi-coloured

LEDs

Mounts to a 4 gang electrical

box.

Table 6 Remote Annunciators (Continued)
