80
Hardware Layouts
DM-1008A
8 Initiating Circuit
Module
MMX-2003-12NDS
MMX-2003-
12NXTDS
MMX-2009-12NDS
MMX-2017-12NDS
ECX-0012
MMX-2000MNS
8 per built-in loop
16 per node
SGM-1004A
4 Notification
Appliance Circuit
Module
MMX-2003-12NDS
MMX-2003-
12NXTDS
MMX-2009-12NDS
MMX-2017-12NDS
ECX-0012
MMX-2000MNS
8 per built-in loop
16 per node
RM-1008A
8 Relay Circuit
Module
MMX-2003-12NDS
MMX-2003-
12NXTDS
MMX-2009-12NDS
MMX-2017-12NDS
ECX-0012
MMX-2000MNS
8 per built-in loop
16 per node
UDACT-300A
Digital Alarm
Communicator
Module
MMX-2003-12NDS
MMX-2003-
12NXTDS
MMX-2009-12NDS
MMX-2017-12NDS
ECX-0012
MMX-2000MNS
1 per system
MR-2300-PR
Polarity Reversal/City
Tie Module
MMX-2003-12NDS
MMX-2003-
12NXTDS
MMX-2009-12NDS
MMX-2017-12NDS
ECX-0012
MMX-2000MNS
1 per node
Table 9 Controller Cards (Continued)
