3. If using an incremental system, perform homing (HOMECMD).
4. Open the Error Correction screen.
On the right side of the screen, enter the position range settings and setting values for error
sampling and correction.
◼ Start position
◼ Number of sampling points
◼ Sampling point interval
◼ Calibration unit (if required)
◼ Index offset (if required)
◼ Load/motor mechanical ratio (if required)
Note The CDHD2S and laser system must have the same physical reference (home) position.
Laser system
5. Use “CARTO Capture - Define Tag” to configure error table.
Select linear definition.
Figure 6-47
6. CARTO Capture - Define Tag > Target menu.
a. Define the following settings. Use the same values from the define configuration in
ServoStudio2:
⚫ First target (the first point that will be measured)
⚫ Last target (the last point that will be measured)
⚫ Interval (distance between measurement points)
⚫ Target per round (total number of points that will be measured)
b. Define one-way travel: The bidirectional option must be cleared.
