Servotronix CDHD2S - Page 24

Specifications
—24—
Single phase
AC 120/240V
Specification
Medium-voltage
CDHD2S-1D5
Medium-voltage
CDHD2S-003
Total power loss
W
Hardware
Unit weight
kg
0.7
0.75
Connecting hardware
PE grounding screw size/torque
M4/1.35Nm
M4/1.35Nm
Line number
Control circuit (AWG) (under 3
meters)
24-28
24-28
Main circuit motor circuit (AWG)
18
18
Main circuit AC input (AWG)
18
18
PE grounding screw
M4
M4
Installations
Installation of Book
Net distance
Left and right (mm)
15
15
Top/bottom (mm)
50
50
Voltage trip
Low voltage trip (nominal) (DC
voltage)
100
100
Overvoltage trip (DC voltage)
420
420
Power supply
temperature
Fan
Usually run at a quarter of power;
when the temperature exceeds the
trigger temperature of the high-
speed fan, it works at full power.
No
Yes
Temperature to trigger high-speed
fan (°C)
NA
45
Power module
Overheating fault regulation (°C)
power module
80±5%
80±5%
Overheating fault unregulation (°C)
power module
NA
45
External regenerative
resistor
(B1+, B2)
External regenerative
resistor requirements
(regenerative resistor is
not provided with the
drive)
Peak current (A)
6.3
12.7
Minimum resistance (Ω)
64
31.5
Power rating (W)
System related
System related
Application information
Internal bus capacitance (µF)
360
660
VLOW (regenerative circuit off) (DC
voltage)
380
380
VMAX (regenerative circuit on) (DC
voltage)
400
400
Table 错误!文档中没有指定样式的文字。-2 Mechanical and electrical specifications-CDHD2S-4D5/CDHD2S-
006 (120/240 VAC)
Single or three phase
AC 120/240V
Specification
Medium-voltage
CDHD2S-4D5
Medium-voltage
CDHD2S-006
Rating
Input power circuit: L1, L2,
L3
Rated voltage (AC voltage line-neutral
point) ±10%
120/240
120/240
Line frequency (Hz)
50/60
50/60
120VAC
1 phase or 3 phase
1 phase or 3 phase
240VAC
1 phase
1 phase
