Specifications
—25—
Single or three phase
AC 120/240V
Specification
Medium-voltage
CDHD2S-4D5
Medium-voltage
CDHD2S-006
Continuous current (1 phase/3 phase,
Arms)
8.5/4
10/5.8
Line fuse (FWP, or equivalent)
10
10
Voltage-endurance (primary to
ground)
1500VAC (2121VDC)
1500VAC (2121VDC)
Control circuit input power
(L1C, L2C)
120±10 or 240±VAC
Single phase
Single phase
STO (safety torque
shutdown)
STO power supply (DC voltage)
24±10%
24±10%
STOFuse(TimeDelay)
120 or 240 VAC (A)
1.5
1.5
Drive output
Continuous output current [Arms]
4.5
6
Continuous output current (Apeak)
6.63
8.48
Peak output current (Arms) 2s
18
18
Peak output current (Apeak) 2s
25.45
25.45
kVA, 120V AC voltage
0.5
0.7
kVA, 240V AC voltage
1.1
1.5
PWM frequency (kHz)
16
16
Soft start
Maximum soft-start surge current (A)
7
7
Maximum charging time (ms)
250
250
Circuit power loss
W
Control circuit loss
W
5
5
Total power loss
W
Hardware
Unit weight
kg
0.97
0.97
Connecting hardware
PE grounding screw size/torque
M4/1.35Nm
M4/1.35Nm
Line number
Control circuit (AWG) (under 3 meters)
24-28
24-28
Main circuit motor circuit (AWG)
16
16
Main circuit AC input (AWG)
16
16
PE grounding screw
M4
M4
Installations
Installation of Book
Net distance
Left and right (mm)
15
15
Top/bottom (mm)
50
50
Voltage trip
Low voltage trip (nominal) (DC
voltage)
100
100
Overvoltage trip (DC voltage)
420
420
Power supply temperature
Fan
Usually run at a quarter of power;
when the temperature exceeds the
trigger temperature of the high-speed
fan, it works at full power.
Yes
Yes
Temperature to trigger high-speed
fan (°C)
45
45
Power module
Overheating fault regulation (°C)
power module
80±5%
80±5%
Overheating fault unregulation (°C)
power module
NA
45
External regenerative
resistor
(B1+, B2)
External regenerative
resistor requirements
Peak current (A)
25.5
25.5
Minimum resistance (Ω)
16
16
