Servotronix CDHD2S - Page 26

Specifications
—26—
Single or three phase
AC 120/240V
Specification
Medium-voltage
CDHD2S-4D5
Medium-voltage
CDHD2S-006
(regenerative resistor is
not provided with the
drive)
Power rating (W)
System related
System related
Application information
Internal bus capacitance (µF)
1120
1120
VLOW (regenerative circuit off) (DC
voltage)
380
380
VMAX (regenerative circuit on) (DC
voltage)
400
400
Table 错误!文档中没有指定样式的文字。-3 Mechanical and electrical specifications
Three phase
AC 400/480V
Specification
High-voltage
CDHD2S-012
High-voltage
CDHD2S-024
High-voltage
CDHD2S-030
Rating
Input power circuit:
L1, L2, L3
Rated voltage (AC voltage
line-neutral point) ±10%
380/480
380/480
380/480
Line frequency (Hz)
50/60
50/60
50/60
380/480VAC
3Phase
3Phase
3Phase
Continuous current (3 phase
Arms)
11.0@400V
9.2@480V
24
30
Line fuse (FWP, or equivalent)
50
100
125
Voltage-endurance (primary
to ground)
1800VAC(2520VDC)
1800VAC
(2520VDC)
1800VAC(2520VDC)
Control circuit input
power (L1C, L2C)
24VDC±10%
24VDC±10%
24VDC±10%
24VDC±10%
STO (safety torque
shutdown)
STO power supply (DC
voltage)
24±10%
24±10%
24±10%
STOFuse(TimeDelay)
24VDC±10%
1.5
1.5
Drive output
Continuous output current
[Arms]
12.0
24
30
Continuous output current
(Apeak)
16.97
33.94
42.3
Peak output current (Arms) 2s
24
72
90
Peak output current (Apeak)
2s
33.84
102
126
kVA, 380V AC voltage
6.22
12.2
15.1
kVA, 480V AC voltage
7.36
15.4
19.0
PWM frequency (kHz)
8
8
8
Soft start
Maximum soft-start surge
current (A)
9
10
10
Maximum charging time (ms)
1300
1500
1500
Circuit power loss
W
Control circuit loss
W
5
5
5
Total power loss
W
Hardware
Unit weight
kg
3.2
10.5
10.5
Connecting
hardware
PE grounding screw
size/torque
M4/1.35Nm
M4/1.35Nm
M4/1.35Nm
Line number
Control circuit (AWG) (under 3
meters)
24-28
24-28
24-28
Main circuit motor circuit
(AWG)
12-14
12
10
Main circuit AC input (AWG)
12-14
12
10
PE grounding screw
M4
M4
M4
