Specifications
—27—
Three phase
AC 400/480V
Specification
High-voltage
CDHD2S-012
High-voltage
CDHD2S-024
High-voltage
CDHD2S-030
Installations
Installation of Book
Net distance
Left and right (mm)
25
30
30
Top/bottom (mm)
50
50
50
Voltage trip
Low voltage trip (nominal)
(DC voltage)
320
320
320
Overvoltage trip (DC voltage)
800
800
800
Power supply
temperature
Fan
Usually run at a quarter of
power; when the temperature
exceeds the trigger
temperature of the high-
speed fan, it works at full
power.
Yes
Yes
Yes
Temperature to trigger high-
speed fan (°C)
76±5%
80±5%
80±5%
Power module
Overheating fault regulation
(°C) power module
100±5%
100±5%
100±5%
Overheating fault
unregulation (°C) power
module
40
NA
NA
External
regenerative resistor
(B1+, B2)
Internal
regenerative resistor
(B1+, B2)
Peak current (A)
23.9
65
65
Resistance (Ω)
22
12
12
Power
300
300
External
regenerative resistor
requirements
(regenerative
resistor is not
provided with the
drive)
Peak current (A)
23.9
100
100
Minimum resistance (Ω)
22
8.4
8.4
Power rating (W)
System related
System related
System related
Application
information
Internal bus capacitance (µF)
820
1640
1640
VLOW (regenerative circuit
off) (DC voltage)
750
750
750
VMAX (regenerative circuit
on) (DC voltage)
770
770
770
Brake output
Opening voltage (VDC) at
24VDC logic supply and rated
current (minimum)
23.5
23.5
23.5
Leakage current when closing
the gate (mA)
<2
<2
<2
Maximum current (A)
1.3
<2
<2
Short circuit protection
Yes
Yes
Yes
Maximum opening time (ms)
20
20
20
Maximum shutdown time
(ms)
20
20
20
