驱动器设置
—64—
Pin
Function
Description
Pin
Function
Description
6
24
7
25
Grounded
Digital ground
8
Analog input 1+
Differential analog command
input high (DC voltage ±
10V)
26
Analog input 1-
Differential analog command
input low (DC voltage ±
10V)
9
27
10
Grounded
Digital ground
28
11
29
Grounded
Digital ground
12
30
13
Grounded
Digital ground
31
Digital input 3
Optoisolated programmable
digital input. Read using IN3
14
Digital input 4
Optoisolated programmable
digital input. Read using IN4
32
Fast digital input 5
Optoisolated programmable
fast digital input. Read using
IN5
33
Digital output 2
Optoisolated programmable
digital output. Read using
OUT2
16
Digital output 3
Optoisolated programmable
digital output. Read using
OUT3
34
17
35
Analog input 2-
Second differential analog
input low (DC voltage ±
10V)
18
*Analog input 2+
Second differential analog
input high (DC voltage ±
10V)
36
*Blank cells indicate unused pins; these pins must remain unwired.
