Chapter 4 Operating Instructions
TR4
70 © SICK AG • Industrial Safety Systems • Germany • All rights reserved 8014467/YTD7/2016-03-30
Subject to change without notice
Mounting
en
Mounting of multiple safety switches
= On mounting several safety switches, observe the minimum distance
stipulated between the individual systems of 200 mm to prevent
mutual interference.
Fig. 4: Minimum
distance for mounting
multiple safety
switches
200 mm
