SICK TR4 User Manual

Chapter 9 Operating Instructions
TR4
94 © SICK AG • Industrial Safety Systems • Germany • All rights reserved 8014467/YTD7/2016-03-30
Subject to change without notice
Technical specifications
en
Minimum Typical Maximum
Surrounding
Ambient operating
temperature
–10 … +55 °C
Relative air humidity 5 %-95 %
Enclosure rating IP 69K
Vibration resistance 3.5 mm/10-55 Hz (EN 60 068-2-6)
Shock resistance 30 g, 11 ms (EN 60 068-2-27)
EMC According to IEC/EN 60 947-5-3
UL Listed Ratings
Standards UL 508, CSA C22.2 No. 14
Power Supply 20 … 30 V DC, Class 2
Ambient Temperature +40 °C max.
Enclosure Rating Type 3, 4X, 12, 13
Tab. 6: Data sheet TR4

SICK TR4 Specifications

General

Number of Safe Outputs	2
Output Type	PNP
Protection Rating	IP67
Type	Safety Switch
Housing Material	Plastic
Supply Voltage	24V DC
Connection Type	Cable
Operating Voltage	24 V DC
Operating Temperature	-25 °C ... +70 °C
Actuator Type	Separate actuator (TR4 Direct, TR4 Standard, TR4 Extended)
