Commissioning
5.3 Quick commissioning using the BOP-2 operator panel
Converter with the CU240B-2 and CU240E-2 Control Units
Operating Instructions, 01/2016, FW V4.7 SP6, A5E34259001B AC
139
8.9.
Motor cooling
SELF
Natural cooling
FORCED
Forced-air cooling
LIQUID
Liquid cooling
NO FAN
Without fan
9.
Select the application:
OP LOOP
Recommended setting for standard applications.
CL LOOP
Recommended setting for applications with short ramp
-
up and ramp
-down times. This setting is not suitable for
hoisting gear and cranes/lifting gear.
HVY LOAD
Recommended setting for applications with a high break
loose torque.
10.
Select the default setting
for the interfaces of the inverter that is suita-
ble for your application.
Default settings of the CU240B-2 interfaces (Page 97)
Default settings of the CU240E-2 interfaces (Page 104)
