Description
3.4 Components for the Power Modules
Converter with the CU240B-2 and CU240E-2 Control Units
Operating Instructions, 01/2016, FW V4.7 SP6, A5E34259001B AC
41
Power Module
Power
Output reactor
GX
6SL3224-0XE41-3UA0
160 kW
6SL3000-2BE33-2AA0
6SL3224-0XE41-6UA0 200 kW 6SL3000-2BE33-8AA0
6SL3224-0XE42-0UA0
250 kW
6SL3000-2BE35-0AA0
Output reactors for PM250 Power Module
Power Module
Power
Output reactor
FSC 6SL3225-0BE25-5☐A0,
6SL3225-0BE27-5☐A0,
6SL3225-0BE31-1☐A0
7.5 kW … 15.0 kW 6SL3202-0AJ23-2CA0
FSD
6SL3225-0BE31-5☐A0
18,5 kW
6SE6400-3TC05-4DD0
6SL3225-0BE31-8☐A0
22 kW
6SE6400-3TC03-8DD0
6SL3225-0BE32-2☐A0
30 kW
6SE6400-3TC05-4DD0
FSE
6SL3225-0BE33-0☐A0
37 kW
6SE6400-3TC08-0ED0
6SL3225-0BE33-7☐A0
45 kW
6SE6400-3TC07-5ED0
FSF
6SL3225-0BE34-5☐A0
55 kW
6SE6400-3TC14-5FD0
6SL3225-0BE35-5☐A0
75 kW
6SE6400-3TC15-4FD0
6SL3225-0BE37-5☐A0
90 kW
6SE6400-3TC14-5FD0
Output reactors for PM230 Power Modules (IP20)
Power Module
Power
Output reactor
FSA 6SL3210-1NE11-3☐L0,
6SL3210-1NE11-7☐L0,
6SL3210-1NE12-2☐L0,
6SL3210-1NE13-1☐L0,
6SL3210-1NE14-1☐L0,
6SL3210-1NE15-8☐L0
0.37 kW … 2.2 kW 6SL3202-0AE16-1CA0
6SL3210-1NE17-7☐L0
3.0 kW
6SL3202-0AE18-8CA0
FSB 6SL3210-1NE21-0☐L0,
6SL3210-1NE21-3☐L0,
6SL3210-1NE21-8☐L0
4.0 kW … 7.5 kW 6SL3202-0AE21-8CA0
FSC 6SL3210-1NE22-6☐L0,
6SL3210-1NE23-2☐L0,
6SL3210-1NE23-8☐L0
11.0 kW … 18.5 kW 6SL3202-0AE23-8CA0
FSD
6SL3210-1NE24-5☐L0
22 kW
6SE6400-3TC03-8DD0
6SL3210-1NE26-0☐L0
30 kW
6SE6400-3TC05-4DD0
FSE
6SL3210-1NE27-5☐L0
37 kW
6SE6400-3TC08-0ED0
6SL3210-1NE28-8☐L0
45 kW
6SE6400-3TC07-5ED0
FSF
6SL3210-1NE31-1☐L0
55 kW
6SE6400-3TC14-5FD0
6SL3210-1NE31-5☐L0
75 kW
6SE6400-3TC15-4FD0
