Description
3.4 Components for the Power Modules
Converter with the CU240B-2 and CU240E-2 Control Units
42 Operating Instructions, 01/2016, FW V4.7 SP6, A5E34259001B AC
Output reactors for PM230 push-through Power Modules
Power Module
Power
Output reactor
FSA
6SL3211-1NE17-7☐L0
3.0 kW
6SL3202-0AE18-8CA0
FSB 6SL3211-1NE21-8☐L0 7.5 kW 6SL3202-0AE21-8CA0
FSC
6SL3211-1NE23-8☐L0
18.5 kW
6SL3202-0AE23-8CA0
Output reactors for PM240-2 Power Module, 200 V
Power Module
Power
Output reactor
FSA 6SL3210-1PB13-0☐L0,
6SL321☐-1PB13-8☐L0
0.55 kW … 0.75 kW 6SL3202-0AE16-1CA0
FSB
6SL3210-1PB15-5☐L0
1.1 kW
6SL3210-1PB17-4☐L0
1.5 kW
6SL3202-0AE18-8CA0
FSB
6SL321☐-1PB21-0☐L0
2.2 kW
6SL3202-0AE21-8CA0
FSC 6SL3210-1PB21-4☐L0,
6SL321☐-1PB21-8☐L0
3 kW … 4 kW
6SL321☐-1PC22-2☐L0,
6SL3210-1PC22-8☐L0
5.5 kw … 7.5 kW 6SL3202-0AE23-8CA0
FSD … FSF: An output reactor is not required.
Output reactors for PM240-2 Power Module, 400 V
Power Module
Power
Output reactor
FSA 6SL3210-1PE11-8☐L1,
6SL3210-1PE12-3☐L1,
6SL3210-1PE13-2☐L1,
6SL3210-1PE14-3☐L1,
6SL3210-1PE16-1☐L1
0.55 kW … 2.2 kW 6SL3202-0AE16-1CA0
6SL321☐-1PE18-0UL1
3 kW
6SL3202-0AE18-8CA0
FSB 6SL3210-1PE21-1☐L0,
6SL3210-1PE21-4☐L0,
6SL321☐-1PE21-8☐L0
4 kW … 7.5 kW 6SL3202-0AE21-8CA0
FSC 6SL3210-1PE22-7☐L0,
6SL321☐-1PE23-3☐L0
11 kW … 15 kW 6SL3202-0AE23-8CA0
FSD … FSF: An output reactor is not required.
Output reactors for the PM240-2 Power Module, 600 V
An output reactor is not required.
