Technical data
10.3 Technical data, Power Modules
Converter with the CU240B-2 and CU240E-2 Control Units
Operating Instructions, 01/2016, FW V4.7 SP6, A5E34259001B AC
449
Table 10- 25 PM240-2, IP20, FSE, 3 AC 500 V … 690 V
Article No. - without filter
Article No. - with filter
6SL3210-…
6SL3210-…
…1PH25-2UL0
…1PH25-2AL0
…1PH26-2UL0
…1PH26 -2AL0
LO base load power
LO base load input current
LO base load output current
45 kW
50 A
52 A
55 kW
59 A
62A
HO base load power
HO base load input current
HO base load output current
37 kW
44 A
42 A
45 kW
54 A
52 A
Siemens fuse according to IEC/UL
Fuse according to IEC/UL, Class J
3NA1 820-0 / 80A
80 A
3NE1 820-0 / 80A
80 A
Power loss without filter
Power loss with filter
1.00 kW
1.00 kW
1.21 kW
1.22 kW
Required cooling air flow
83 l/s
83 l/s
Weight without filter
Weight with filter
26 kg
28 kg
26 kg
28 kg
Table 10- 26 PM240-2, IP20, FSF, 3 AC 500 V … 690 V
Article No. - without filter
Article No. - with filter
6SL3210-…
6SL3210-…
…1PH28-0UL0
…1PH28-0AL0
…1PH31-0UL0
…1PH31-0AL0
…1PH31-2UL0
…1PH31-2AL0
LO base load power
LO base load input current
LO base load output current
75 kW
78 A
80 A
90 kW
97 A
100 A
110 kW
111 A
115 A
HO base load power
HO base load input current
HO base load output current
55 kW
66 A
62 A
75 kW
85 A
80 A
90 kW
106 A
100 A
Siemens fuse according to IEC/UL
Fuse according to IEC/UL, Class J
3NE1 021-0 / 100 A
100 A
3NE1 022-0 / 125 A
125 A
3NE1 224-0 / 160 A
150 A
Power loss without filter
Power loss with filter
1.34 kW
1.35 kW
1.71 kW
1.72 kW
2 kW
2.02 kW
Required cooling air flow
153 l/s
153 l/s
153 l/s
Weight without filter
Weight with filter
60 kg
64 kg
60 kg
64 kg
60 kg
64 kg
