Recipes 6-5SIMATIC PCS 7 OSx 4.1.2 Operator
Figure 6-3 shows the Recipe Selection display.
Load
Clear Selected
Recipe
Close Help
Figure 6-3 Recipe Selection Display
Recipe Area The Recipe Area field displays the name of the designated
recipe area; fills automatically when the screen is accessed.
Description The Description field displays a description of the recipe
area; fills automatically when you access the screen.
Recipe Loaded The Recipe Loaded field displays the name of the recipe
previously downloaded.
Recipe Selected The Recipe Selected field displays the recipe currently
selected.
Recipe The Recipe field lists all recipes validated for that area.
Description The Description field displays the description of the recipe as
entered in the Recipe Configuration Directory.
Load The
Load button creates a production recipe and accesses the
Production Recipe Preparation display.
Clear Selected Recipe The
Clear Selected Recipe button allows the
operator to deselect the recipe for the recipe area.
