Reports
9-
27
SIMA
TIC
PCS
7
OSx
4.1.2
Operator
T
o
print
an
OSxess
report
output,
select
File
-
-
>Print
from
the
menu
bar
(
Figure
9-
18
).
Both
th
e
Print
and
Print
As...
me
nu
o
ption
s
are
d
iscusse
d
in
the
XESS
User
’s
Guide
,
Chapter
1
1,
“Print
ing
the
Spreadsheet.”
Figure
9
-18
Printing
Report
Output
(OSxess)
218
220
Table of Contents
Default Chapter
7
Table of Contents
7
Preface
17
Chapter 1 Osx Station Basics
23
Accessing Menu Bar Functions
23
Hardware Overview
24
AC Power Requirements
24
Hardware Components
25
Other Network Nodes
26
Other Network Connections
26
SIMATIC PCS 7 Osx Hardware Components
27
PCS 7 Osx Stations
28
Osx Station (Single-Station System)
28
Single Osx Station System Architecture
29
Osx Stations (Multiple-Station System)
30
Multiple-Station System Architecture
30
S7-416 Controllers that Support 12 Osx Stations
31
S7-414 Controllers that Support Eight Osx Stations
31
Other Nodes
35
Osx Station Operation Restrictions
36
Customized Files
36
Action Request Display
38
Assigning Deadband Values
38
Terminals and Loss of Primary
38
Accessing Menu Bar Functions
40
Tasks Supported by Osx Stations
43
Tasks Supported by an Osx Station Based on Type
43
Tasks Supported by Non-Primary Osx Stations
44
Basic System Functions
45
Powering up
45
How to Log on
45
Logon Dialog Box
45
Powering down
46
Shutting down the System
46
Changing System State
48
Osx Change System State Dialog Box
50
Operator Keyboard Functions
52
Operator Keyboard
52
Screen Hierarchy Display Keys
53
Identifying Screen Areas
54
Main Screen Areas
54
Osx Main Screen and Information Area
55
Navigation Area Icons
56
Displaying the Runtime Directory
57
Navigation Area Display Options
57
Navigation Area Directory
57
Working in Windows
58
Screen Elements
59
Moving and Resizing Windows
61
Layer Attributes Dialog Box
63
Using Navigational Tools to Enter Data
64
Displaying a Short List of Items
66
Displaying a Long List of Items
67
Displaying the Long List Default Screen
68
Locating an Item in a Long List: Incremental Method
69
Using the Tag Filter
71
Filtering Using a Second Variable
72
Resetting to the Original Tag List
73
Displaying Covered Windows
75
Locating an Item from the Directory: Filter Method
75
Displaying Graphics
76
Displaying a Graphic
76
Displaying a Window Group
77
Using Function Keys to Display Graphics
78
Using Reflection X
79
Refreshing Graphics that Have Symbols
80
Screen Hierarchy
81
Accessing Displays from the Hierarchy
81
Accessing Displays with Screen Hierarchies and Associations
81
Screen Hierarchy
82
Example of a Screen Hierarchy Design
82
Chapter 2 Osx Station Control
84
Displaying Osx Station Commands
84
Issuing Commands to Osx Stations
85
Re_Sync Command
86
Osx Station Status
87
Role_Change Command
89
Single-Station System
89
Multiple-Station System
90
Role Change Notification
91
Attempting to Change Roles Without an Active Primary
91
Making Role Changes
92
Role Changes Possible for an Osx Station
94
Role Change, Reports, BCL, and RDT
95
Automatic Role Changes
96
New_Primary Command
98
Switch_Media Command
99
Handling a Failover
100
What Is Failover
100
When Failover Occurs
100
Failover Configuration for a Multiple-Station System
101
Chapter 3 Tag Detail
103
Tag Detail Displays
104
Defining a Tag
104
Displaying a Tag Detail
105
Tag Detail Directory
105
Changing Tag Detail Values in the Operate State
106
Tag Detail Display
106
Tag Detail Command Form
107
Tag Detail Examples
108
Digital Output (DO) Tag Example
108
Digital Output Tag Detail
108
Loop Tag Example
109
Loop Tag Detail
109
Tag Group Displays
110
Displaying a Tag Group
111
Tag Group Directory
111
Tag Group Display
112
Chapter 4 Trends
113
Displaying Trend Data
114
Accessing the Trend Directory
114
Real-Time Trend Displays
114
Historical Trend Displays
116
Doubling the Size of Trend Displays
118
Changing the Time Base or Range
120
Refreshing a Trend
121
Displaying Trend Data in a Graphic
122
Reading Disk Space Information
123
Chapter 5 Alarms
125
Alarm Notification and Acknowledgment
126
Alarm Priority Indicators
126
Alarm Acknowledgment by Priority
130
Alarm Group Display
132
Alarm Mini-Windows
134
Alarm Log
136
Alarm Log Entry Types and Alarm Priorities
137
System Alarms
138
Alarms and Osx Station Synchronization
140
Chapter 6 Recipes
141
Introduction
141
Controller Recipes
141
Osx Recipes
141
Identifying Recipe Areas
141
Selecting Recipes for Download
144
Preparing to Download Recipes
144
Accessing the Recipe Selection Display
144
Downloading a Recipe
146
Planning a Recipe Download
146
Clearing the Selected Recipe
147
Loading a Recipe
148
Modifying Recipe Component Values
150
Modifying Production Recipe Values
150
Modifying Scale Values
151
Loading a Production Recipe
152
Printing a Production Recipe
152
Canceling a Download Request
152
Suspending a Recipe Download
152
Continuing a Recipe Download
152
Chapter 7 Action Requests
154
Understanding Action Requests
154
Introduction
154
Monitoring Action Requests
155
General Guidelines
155
Action Request Mini-Windows
157
Responding to Action Requests
158
Selecting the Action Request Icon
158
Responding to an Action Request
161
General Guidelines for Answering an Action Request
163
Action Requests During Osx Station Synchronization
163
Responding to Different Action Request Types
164
Multi-Choice
165
Acknowledge
165
Enter Value
166
View
166
Event Log
166
Example of Responding to Action Requests
167
Starting the Process
168
Answering the BATCH_SELECT Action Request
168
Adding a Catalyst to the Reactor Tank
169
Filling the Reactor Tank
169
Answering the SET_TEMP Action Request
170
Heating the Mixture
171
Finishing the Process
171
Chapter 8 Batch
173
Assigning a Batch
174
Displaying a List of Active Batches
177
Displaying the Active Batch Tag Group
178
Viewing the Operation of an Active Batch
179
Synchronizing During Program Execution
179
Viewing Batch-Related Graphics
179
Viewing a Batch Tag Detail
179
Assigning Batch Units
180
Releasing Batch Units
181
Changing Batch State
182
Changing the State of a Batch
182
Starting a Batch
182
Changing Batch Mode
183
Splitting a Batch
184
Ending a Batch
185
Completing or Aborting a Batch
185
Removing a Batch
186
Viewing Batch-Related Tag Groups
187
Displaying UNIT Tag Groups from the Batch Detail
187
Viewing the Unit Tag Detail and Faceplate
188
Viewing Unit Tag Detail
188
Changing the State of a Unit
189
Changing the Mode of a Unit
190
Viewing the Unit Faceplate
191
Chapter 9 Reports
193
Displaying the Reports Directory
194
Accessing the Reports Directory
194
Selecting a Report Format
195
Copying and Deleting a Report
196
Copying a Report
196
Deleting a Report
197
Scheduling a Report
198
The Report Scheduler
198
Accessing the Scheduler
198
Scheduler Fields
200
Suspending or Activating a Report
201
Scheduling a Report by Time
202
Scheduling a Report by Event
206
Adding a New Schedule
207
Showing the Next Schedule
207
Scheduler Example
207
Editing and Saving a Schedule
207
Setting the Report Output Destination
208
Printing a Format
209
Previewing a Report
210
Printing a Previewed Report
213
Error Messages
213
Viewing Error Files
213
Report Output Directory
214
Displaying the Report Output
214
Viewing a Report Output
216
Printing an Output
218
Deleting an Output
220
Advanced Task References
221
