Siemens SIMATIC S7-1500 Motion Control V13 User Manual

Configuring
6.8 Parameter view
S7-1500 Motion Control V13 Update 3
168 Function Manual, 07/2014, A5E03879256-AC
6.8.4.7
Monitoring values online in the parameter view
You can monitor the values currently taken by the parameters of the technology object in the
CPU (monitor values) directly in the Parameter view.
Requirements
● There is an online connection.
● The technology object is downloaded to the CPU.
● The Parameter view of the technology object is open.
Procedure
As soon as the Parameter view is online, the following columns are additionally displayed:
● Compare result
● Start value PLC
● Monitor value
● Modify value
● Selection for transmission
The "Monitor value" column shows the current parameter values on the CPU.
Display
All columns that are only available online have an orange background:
● Values in light-orange cells
can be changed.
● Values in cells with a dark orange background
cannot be changed.
See also
Parameter table (Page 162)
