Appendix
A.2 Tags of the positioning axis/synchronous axis technology object
S7-1500 Motion Control V13 Update 3
Function Manual, 07/2014, A5E03879256-AC
347
A.2.19
StandstillSignal tags (positioning axis/synchronous axis)
The tag structure <TO>.StandstillSignal.<tag name> contains the configuration for the
standstill signal.
If the actual velocity value is below the velocity threshold, and does not exceed it during the
minimum dwell time, then the standstill signal <TO>.StatusWord.X7 (Standstill) is set.
Tags
Legend (Page 332)
Tag
Data type
Values
W
Description
StandstillSignal. STRUCT Configuration for the standstill signal
VelocityThreshold LREAL 0.0 to 1.0E12 DIR Velocity threshold
If velocity is below this threshold, then the minimum
dwell time begins.
MinDwellTime
LREAL
0.0 to 1.0E12
DIR
Minimum dwell time
See also
Evaluating the technology data block (Page 173)
A.2.20
StatusPositioning tags (positioning axis/synchronous axis)
The tag structure <TO>.StatusPositioning.<tag name> indicates the status of a positioning
motion.
Tags
Legend (Page 332)
Tag
Data type
Values
W
Description
StatusPositioning.
STRUCT
Distance
LREAL
-
RON
Distance to the target position
TargetPosition
LREAL
-
RON
Target position
FollowingError
LREAL
-
RON
Current following error
See also
Evaluating the technology data block (Page 173)
