Commissioning
9.4 Optimization
S7-1500 Motion Control V13 Update 3
Function Manual, 07/2014, A5E03879256-AC
211
The following trace recording shows a curve with a long settling time:
The following trace recording shows a curve with overshoot when approaching the setpoint:
