Siemens SINUMERIK 802D sl Function Manual

Gantry axes (G1)
6.8 Data lists
Turning, Milling, Nibbling
Function Manual, 11/2012, 6FC5397-1CP10-5BA0
113
Number Identifier Name
37110 GANTRY_POS_TOL_WARNING Gantry warning limit
37120 GANTRY_POS_TOL_ERROR Gantry trip limit
37130 GANTRY_POS_TOL_REF Gantry trip limit for referencing
37140 GANTRY_BREAK_UP Invalidate gantry axis grouping
6.8.2 Interface signals
Number Bit Name Leading axis Synchronized axis
Mode-specific
V3100 0001 .2 Active machine function REF - -
Channel-specific
V3300 0001 .0 Referencing active - -
Axis-specific
V380x 5005 .4 Start gantry synchronization x -
V380x 5005 .5 Automatic synchronization locking x -
V390x 0000 .4 Referenced/synchronized 1 - -
V390x 5005 .2 Gantry trip limit exceeded - x
V390x 5005 .3 Gantry warning limit exceeded - x
V390x 5005 .4 Gantry synchronization ready to start x -
V390x 5005 .5 Gantry grouping is synchronized x -
V390x 5005 .6 Gantry leading axis 1 0
V390x 5005 .7 Gantry axis 1 1
x ≙ relevant for ...
