15.2.7 Signal monitoring
Oscillating signal
Owing to aging of the punch hydraulics, overshooting of the punch may cause the "Stroke
active" signal to oscillate at the end of a stroke.
In this case, an alarm (22054 "Undefined punching signal") can be generated depending on
MD26020 NIBBLE_SIGNAL_CHECK.
Reset response
In the case of an NCK reset, IS V3300 0006.0 (stroke initiation active) is cancelled
immediately without acknowledgement by the high-speed input.
A currently activated stroke cannot be suppressed.
15.3 Activation and deactivation
15.3.1 Language commands
Punching and nibbling functions are activated and deactivated via configurable language
commands. These replace the special M functions that were used in earlier systems.
Reference:
/BPN/ Operation and Programming, Nibbling
Groups
The language commands are subdivided into the following groups:
Group 35
The actual punching and nibbling-specific functions are activated and deactivated by means of the
following language commands:
PON
= punching ON
SON
= nibbling ON
PONS
= punching ON, activated in the position controller
SONS
= nibbling ON, activated in the position controller
SPOF
= punching/nibbling OFF
