Siemens SINUMERIK 802D sl Function Manual

Tool: Compensation and Monitoring (W1)
25.4 Tool monitoring
Turning, Milling, Nibbling
Function Manual, 11/2012, 6FC5397-1CP10-5BA0
425
Activating the tool offset
D1 to D9 activates the tool compensation (offset) for a cutting edge on the active tool. Tool
length compensation and tool radius compensation can be activated at different times:
● Tool length compensation (TLC) is performed on the first traversing motion of the axis on
which the TLC is to act. This traversing motion must be a linear interpolation (G0, G1).
● Tool radius compensation (TRC) becomes active when G41/G42 is programmed in the
active plane (G17, G18 or G19). The selection of tool radius compensation with G41/G42
is only permitted in a program block with G0 (rapid traverse) or G1 (linear interpolation).
Detailed description of the tool compensation (offset) including tool radius compensation:
Reference:
/BP_/ Operation and Programming, Section "Tool and tool offset"
25.4 Tool monitoring
Note
This function is not available with T/M value.
25.4.1 Tool monitoring overview
General
The tool monitoring is activated via the following machine data:
● MD18080 MM_TOOL_MANAGEMENT_MASK: Bit 1=1
● MD20310 TOOL_MANAGEMENT_MASK: Bit 1=1
The "Tool monitoring" function works without active tool management and allows the
following monitoring types of the active cutting edge of the active tool for SINUMERIK 802D
sl:
● Monitoring of the tool life
● Monitoring of the workpiece count
The above mentioned monitoring types can be activated simultaneously for a tool.
