Operating Modes, Program Operation (K1)
10.4 Program test
Turning, Milling, Nibbling
194 Function Manual, 11/2012, 6FC5397-1CP10-5BA0
Selection/activation
Operation with dry run feedrate is selected in the "Position" operating area -> "Program
control" softkey (AUTOMATIC mode). IS "Dry run feedrate" (V1700 0000.7) is set on
selection of the function. In addition, the required dry run feedrate must be entered in the
menu "Setting data". This does not activate the function.
This function is activated via the IS "Activate dry run feedrate" (V3200 0000.4) and is
evaluated at NC start.
The dry run feedrate must be entered before program start in SD42100 DRY_RUN_FEED.
Display
The checkback signal that dry run feedrate is active is displayed in the relevant "DRY" status
line on the user interface.
10.4.5 Block search: Processing of certain program sections
Functionality
To set the program run to a certain block (target block) of a part program, the block search
function can be used. It can be selected whether or not the same calculations are to be
performed during the block search up to the target block as would be performed during
normal program operation.
After the target block is reached, the part program can be started via IS "NC Start" (give 2x)
(V3200 0007.1). If necessary there is an automatic compensating movement of the axes to
start or end positions of the target block. Execution of the remaining program then continues.
NOTICE
Pay attention to a collision-free start position and appropriate active tools and other
technological values! If necessary, a collisionfree start position must be approached
manually with JOG. Select the target block considering the selected block search type.
