Operating Modes, Program Operation (K1)
10.3 Processing a part program
Turning, Milling, Nibbling
Function Manual, 11/2012, 6FC5397-1CP10-5BA0
177
The effect of commands/signals
The program status can be controlled by activating different commands or interface signals.
The following table shows the resulting program state when these signals are set (status
before the signal is set -> Program status running).
Table 10- 5 Effect on program status
Program execution states
Commands
Aborted Interrupted Stopped Running
IS "Reset" X
IS "NC Stop" X
IS "NC stop at block limit" X
IS "NC stop axes and spindles" X
IS "Read-in disable" X
IS "Feed stop, channel-sp." X
IS "Feed stop, axis-sp." X
Feed override = 0% X
IS "Spindle stop" X
M2 in the block X
M0/M1 in the block X
IS "Single block" X
Auxiliary functions output to PLC but not
yet acknowledged
X
10.3.7 Channel status
Channel states
The current channel status is signaled at the interface for the channel. The PLC can then
trigger certain responses and interlocks configured by the manufacturer depending on the
status at the interface. The channel status is displayed in all operating modes.
The following channel states are available:
● IS "Channel status reset" (V3300 0003.7)
● IS "Channel status interrupted" (V3300 0003.6)
● IS "Channel status active" (V3300 0003.5)
The effect of commands/signals
The channel status can be modified through the activation of various commands or interface
signals. The following table shows the resulting channel status when these signals are set
(assumed status before the signal is set - > Channel status active).
