Operating Modes, Program Operation (K1)
10.2 Operating modes
Turning, Milling, Nibbling
172 Function Manual, 11/2012, 6FC5397-1CP10-5BA0
10.2.4 Interlocks in the individual modes
Overview of interlocks
Different interlocks can be active in the different operating modes.
The following table shows which interlocks can be activated in which operating mode and in
which operating state.
Mode of operation AUTO JOG MDI
Functions 1 2 3 1 3 4 3 5 3 1 2 3 6 7
General interlocks
802 Ready x x x x x x x x x x x x x x
Mode change disable x x x x x x x x x x x x x x
Channel-specific interlocks
Feed stop x x x x x x x
NC Start disable x x x x x x x x x x x x x x
Read-in disable x x x x x x x x x x x x x x
Axis-specific interlocks
Spindle disable x x x x x x x x x x x x x x
Controller disable x x x x x x x x x x x x x x
Axis disable x x x x x x x x x x x x x x
Spindle-specific interlocks
Controller disable x x x x x x x x x x x x x x
Spindle disable
x x x
x x x x x x
x x x x x
x: Interlock can be activated in this status
1: Channel in reset
2: Channel interrupted
3: Channel active
4: Channel interrupted JOG during AUTOMATIC interruption
5: Channel interrupted JOG during MDA interruption
6: Channel active JOG in MDA during MDA interruption
7: Channel active JOG in MDA
