Operating Modes, Program Operation (K1)
10.7 Data lists
Turning, Milling, Nibbling
Function Manual, 11/2012, 6FC5397-1CP10-5BA0
203
Number Identifier Name
20150 GCODE_RESET_VALUES Reset G groups
20152 GCODE_RESET_MODE G code basic setting at RESET
Auxiliary function settings of the channel
Number Identifier Name
Channel-specific
22000 AUXFU_ASSIGN_GROUP[n] Auxiliary function group [aux. func. no. in
channel]: 0...63
22010 AUXFU_ASSIGN_TYPE[n] Auxiliary function type [aux. func. no. in
channel]: 0...63
22020 AUXFU_ASSIGN_EXTENSION[n] Auxiliary function extension [aux. func. no. in
channel]: 0...63
22030 AUXFU_ASSIGN_VALUE[n] Auxiliary function value [aux. func. no. in
channel]: 0...63
22550 TOOL_CHANGE_MODE New tool offset for M function
Timers and counters of the channel
Number Identifier Name
Channel-specific
27860 PROCESSTIMER_MODE Activation of the program runtime
measurement
27880 PART_COUNTER Activation of the workpiece counters
27882 PART_COUNTER_MCODE[n] Workpiece counting via M command, n = 0 ...
2
Display machine data
Number Identifier Name
283 ... 292 Setting of the display for the graphic
simulation
10.7.2 Setting data
Number Identifier Name
Channel-specific
42000 THREAD_START_ANGLE Start angle for thread
42010 THREAD_RAMP_DISP Starting and deceleration distance of feed axis in
thread cutting G33
42100 DRY_RUN_FEED Dry run feedrate
