Reference Point Approach (R1)
18.6 Data lists
Turning, Milling, Nibbling
330 Function Manual, 11/2012, 6FC5397-1CP10-5BA0
Note
The control may not always recognize the need for recalibration. If it detects such a need, it
sets MD34210 to 0 or 1. The following is detected: changeover to another gear speed with a
different gear ratio between the encoder and load.
In all other cases, the user must overwrite MD34210.
Data backup
When machine data is backed up, the status of MD34210 ENC_REFP_STATE is also saved.
By loading this data set, the axis is automatically deemed calibrated!
WARNING
If the data set has been taken from another machine (e.g. series startup), calibration must
still be carried out after loading and activating the data.
18.6 Data lists
18.6.1 Machine data
Number Identifier Name
Channel-specific
20700 REFP_NC_START_LOCK NC-Start disable without reference point
Axis-specific
30200 NUM_ENCS Number of encoders
30240 ENC_TYP[0] Actual value encoder type
30330 MODULO_RANGE Magnitude of modulo range
30340 MODULO_RANGE_START Starting position of modulo range
31122 BERO_DELAY_TIME_PLUS[0] BERO delay time in plus direction
31123 BERO_DELAY_TIME_MINUS[0] BERO delay time in minus direction
34000 REFP_CAM_IS_ACTIVE Axis with reference cam
34010 REFP_CAM_DIR_IS_MINUS Reference point approach in minus direction
34020 REFP_VELO_SEARCH_CAM Reference point approach velocity
34030 REFP_MAX_CAM_DIST Maximum distance to reference cam
34040 REFP_VELO_SEARCH_MARKER[0] Reference point creep speed
34050 REFP_SEARCH_MARKER_REVERSE[0] Direction reversal to reference cam
