Manual and Handwheel Travel (H1)

8.6 Data lists

Turning, Milling, Nibbling

Function Manual, 11/2012, 6FC5397-1CP10-5BA0

155

8.6.3 Interface signals

Number Bit Name

Signals from HMI to PLC

V1900 1003 .0 to .2 Axis number for handwheel 1

V1900 1004 .0 to .2 Axis number for handwheel 2

NCK-specific

V2600 0001 .0 INC inputs in operating mode range active

Specific to operating mode

V3000 0000 .2 JOG mode

V3000 0002 .0 to .6 Machine function INC1 up to continuous in operating mode range

V3100 0000 .2 Active JOG mode

Channel-specific

V3200 1000

V3200 1004

V3200 1008

.1, .0

Activate handwheel (2, 1) for geometry axis 1

for geometry axis 2

for geometry axis 3

V3200 1000

V3200 1004

V3200 1008

Traversing-key lock for geometry axis 1

for geometry axis 2

for geometry axis 3

V3200 1000

V3200 1004

V3200 1008

Rapid traverse override for geometry axis 1

for geometry axis 2

for geometry axis 3

V3200 1000

V3200 1004

V3200 1008

.7 or .6

Traversing keys plus or minus for geometry axis 1

for geometry axis 2

for geometry axis 3

V3200 1000

V3200 1004

V3200 1008

.0 to .6

Machine function INC1 to continuous for geometry axis 1

for geometry axis 2

for geometry axis 3

V3300 1000

V3300 1004

V3300 1008

.1, .0

Handwheel active (2, 1) for geometry axis 1

for geometry axis 2

for geometry axis 3

V3300 1000

V3300 1004

V3300 1008

.7 or .6

Traverse command plus or minus for geometry axis 1

for geometry axis 2

for geometry axis 3

V3300 1001

V3300 1005

V3300 1009

.0 to .6

Active machine function INC1 to continuous

for geometry axis 1

for geometry axis 2

for geometry axis 3

Axis/spindle-specific

VB380x 0000 - Feed override

V380x 0000 .7 Override active

V380x 0002 .2 Delete distance-to-go

V380x 0004 .1, .0 Activate handwheel (2, 1)

V380x 0004 .4 Traversing-key lock

V380x 0004 .5 Rapid traverse override

V380x 0004 .7 or .6 Traversing keys plus or minus

V380x 0005 .0 to .6 Machine function INC1 up to continuous in axis range
